Sheep Yard Sample Designs

ProWay products are proudly designed and manufactured in Australia, and installed all over the world.

20 Years of Quality Design and Manufacturing Experience

All livestock enterprises have unique requirements, because of this the best stockyard design is the one that is tailored to suit your operation.

ProWay don’t sell yards straight out of a catalogue. We use our range of standard designs as a benchmark for working capacity which are then fine-tuned to meet the individual needs of our clients. In many cases we design from scratch, drawing on our extensive design library to create a facility specific to your needs.

Sheep Yard Sample Designs

ProWay yards are built to last generations, that’s why the design is so important

Details such as operator and vehicle access, where gates swing from, gate length, yard orientation, corners in yards and pen size, all influence stock flow.

All ProWay facilities are drawn in CAD software to ensure measurements are accurate and fit as designed come construction.

Sheep Yard Sample Designs

Proway’s Design Advantage

ProWay measure your site with survey and satellite data to record relevant existing fence lines, elevation, roof structures, trees and other infrastructure or services which can be factored into your new facility. This provides a significant advantage and cost saving as in many cases, existing holding yards or structures can be utilised in the new build.

For green field sites we work with you to ensure site selection will best suit your property including best access for stock, operators and trucks.

Sheep Yard Sample Designs

On top of your design, we provide site preparation guides which can include recommended new fence lines, laneways and earthworks, as well as turning circles for semi and b-double trailers so you can be sure everything fits.

Below are a selection of our standard designs for varied working capacities

PSY 525
PSY 525 Specification

FILLED COMPLETE CAPACITY: 664 head

PRE-DRAFT CAPACITY: 356 head

POST-DRAFT CAPACITY: 308 head

(based on 2 head / sqm)

WORKING RACE LENGTH: 13.5m

Key Features Include:

  • Sheeted bugle leadup to working area
  • Adjustable V-Draft race
  • Curved flat top working race
  • 5-Way Diamond Yard for flexibility
  • 2 x draft points
  • Tumble swing gate mid race
  • Guillotine gate race exit
  • Customised to suit your operation
PSY 780 (with serpentine draft)
PSY 780 (with serpentine draft) Specification

FILLED COMPLETE CAPACITY: 1,058 head

PRE-DRAFT CAPACITY: 592 head

POST-DRAFT CAPACITY: 466 head

(based on 2 head / sqm)

WORKING RACE LENGTH: 13m

Key Features Include:

  • Sheeted bugle leadup to working area
  • Serpentine draft
  • 2 x draft points
  • Flat top race with release gates
  • Tumble swing gate mid race
  • Guillotine gate race exit
  • Diamond yard at race exit
  • Customised to suit your operation and sheep handler if applicable
PSY 1100
PSY 1100 Specification

FILLED COMPLETE CAPACITY: 1,430 head

PRE-DRAFT CAPACITY: 700 head

POST-DRAFT CAPACITY: 730 head

(based on 2 head / sqm)

WORKING RACE LENGTH: 13.3m

Key Features Include:

  • Sheeted bugle leadup to working area
  • Adjustable V-Draft race
  • Dual flat top working race
  • Double tumble swing gates mid race
  • Double guillotine gates race exit
  • 2 x diamond yards for flexibility
  • 2 x draft points
  • Customised to suit your operation and sheep handler if applicable
PSY 1275 (with serpentine draft)
PSY 1275 (with serpentine draft) Specification

FILLED COMPLETE CAPACITY: 1,654 head

PRE-DRAFT CAPACITY: 842 head

POST-DRAFT CAPACITY: 812 head

(based on 2 head / sqm)

WORKING RACE LENGTH: 12.3m

Key Features Include:

  • Sheeted bugle leadup to working area
  • Serpentine draft race
  • Curved dual flat top working race
  • Double tumble swing gates mid race
  • Double guillotine gates race exit
  • Diamond yard offers 4-way draft
  • 2 x draft points
  • Customised to suit your operation and sheep handler if applicable
PSY 2880
PSY 2880 Specification

FILLED COMPLETE CAPACITY: 4,650 head

PRE-DRAFT CAPACITY: 2,500 head

POST-DRAFT CAPACITY: 2,100 head

(based on 2 head / sqm)

WORKING RACE LENGTH: 13.3m

Key Features Include:

  • ProWay Sheep Rotary Force
  • Dual flat top working Race
  • Adjustable V-Draft Race
  • 3 x Diamond Yards for flexibility
  • Draft lane ideal for filling shearing shed
  • Diversion to loading Ramp
  • Customised to suit your operation and sheep handler if applicable

Looking for more Sheep Yard Designs?

Get in touch and let us know your specific handling requirements and/or working capacity and we’ll send you a sheep yard design pack.
